Pure Humidifier EC-10 User Manual

TM
Dimensions & Layout
*Removable access plate allows reservoir to slide out
for inspection and cleaning without disconnecting the
steam supply piping.
**See local codes for minimum clearance to
electrical compartment. The electrical access
door requires a minimum clearance of 16” to fully
open.
Key Locked Electrical
Access Door**
Removable
Access Plate*
Removable Key Locked
Reservoir Access Door
Touchscreen/
Operation Status
Indicating Lights
Key Locked
Electrical Access
Door
FRONT VIEW
RIGHT SIDE VIEW
BOTTOM VIEW
Note: Dimensions are typical for all EC models.
R
Rem
o
v
ab
l
e
A
A
A
Acc
ess
Pl
a
t
e*
TOP VIEW
17.00”
(43.2)
7.75”
(19.7)
2 3/8” Steam
Outlet Access
14.75”
(37.5)
16”
(40.6)
29.50”
(74.9)
24”
(60.9)
6.50”
(16.5)
2.375”
(6.0)
Reservoir Drain Outlet
1 7/8ӯ
15.00”
(38.1)
8.4375”
(21.4)
2.00”
(5.1)
1.50”
(3.8)
Electrical Inlet 1 1/8ӯ
Water Inlet 3/8” NPT
Cabinet Overfl ow
1/2” NPT
3
