Pure Humidifier EC-5 Installation Instructions

1
Introduction
To the user of PURE Humidifier Co.’s
Electric Humidifiers
We at PURE Humidifier Co. thank you for choosing
one of our quality products. PURE Humidifier Co.
Electric Series Humidifiers are models of simplicity
to install, operate, and maintain. However, they
must be maintained to provide maximum operating
efficiency.
PLEASE READ AND FOLLOW ALL
INSTRUCTIONS CAREFULLY. PROPER
OPERATION AND HUMIDITY CONTROL IS
POSSIBLE ONLY WITH PROPER INSTALLATION
AND MAINTENANCE.
The “EC” Series Humidifier utilizes a Tri-Probe
Sensor conductive-type water control system, which
is designed for use with standard (hard or soft) tap
water. Use of deionized, demineralized, or reverse
osmosis water will cause a failure of the water level
control system and void the warranty.
High chloride content in feed water can cause
chloride stress cracking and chloride pitting in
stainless components. Chloride stress corrosion
cracking (CSCC) and chloride pitting of stainless
steel components is not covered by warranty. Do
not use hydrochloric acid descalers or bleach to
clean the tank. We offer an easy-to-use, non-toxic
descaling solution to help keep your units clean and
operating with maximum efficiency. Please contact
your local PURE Humidifier representative for more
information about our PURE Clean descaling
solution.
PURE Humidifier Co.’s “ECDDR” Series should be
installed on applications that require deionized,
demineralized, or reverse osmosis water.
To ensure proper installation of this product, it must
be installed by qualified HVAC and electrical
contractors, and must be in compliance with local,
state, federal, and governing codes. If installed
improperly this product may cause damage to
property, severe personal injury, or death as a result
of electric shock, burns, and/or fire.
Do not adjust any components inside humidifier
control panel without consulting the factory.
Installation of humidifier in high humidity or salt
water atmospheres will cause accelerated corrosion,
resulting in a reduction of the normal lifespan of the
unit.
For indoor use only.
Table of Contents
Introduction 1
Capacity & Electrical Specifications 2
Dimensions & Layout 3
Humidifier Layout 4
Location & Mounting 5
Wall Mounting Detail 6
Dispersion Methods 7
Injection Tube and Flexible Hose 8
Steam Supply Piping Examples 9
Piping 10
Blower Pack 11-12
Pre-Startup Checklist 13
Non-INTAC
®
Startup Procedure 14
INTAC
®
Startup Procedure 15
Maintenance & Cleaning Instructions 16
Cover Gasket Replacement Instructions 17
Troubleshooting 18
Tool Requirements & Torque List 19
Maintenance Notes 20
Exploded Parts Drawing 21
Parts List 22
The PURE Humidifier Co. Warranty
PURE Humidifier Co. guarantees its products to be free from
defects in material and workmanship for a period of one year
from the date of shipment; provided the product is properly
installed, serviced, and put into the service for which it was
intended.
PURE Humidifier Co. is obligated under the terms of this
warranty to the repair or replacement of the defective part(s),
excluding any labor charges, or to refund the purchase price at
our option. PURE Humidifier Co. assumes no obligation for
incidental or consequential damages. The above provisions
are in lieu of all other guarantees, obligations, liabilities or
warranties, expressed or implied.

Pure Humidifier EC-5 Specifications

General

Brand	Pure Humidifier
Model	EC-5
Category	Humidifier
Language	English
