4
Listening to radio
Listening to radio
Adjusting the volume
(From menus and ReVu
®
)
Switching between DAB and FM
Press the DAB/FM button.
Changing stations
When listening to DAB
1. Press the Stations button to display the station list on the bottom line of the display.
2. Turn the dial right or left to scroll through the list of available DAB stations. The name of the
current station remains at the top of the screen.
3. Push the dial to change the station.
When listening to FM
Seek Tuning
Press the Stations button and rotate the dial right or left to seek to the next or previous FM
station that has a strong signal.
Manual Tuning
1. Change the FM tuning mode to ‘Manual’ (see page 9).
2. Press the Stations button then rotate the dial right or left to step up or down 0.05 MHz.
Volume
DAB/FM
Stations
Stations
Virgin Radio
BBC Radio 2
87.60MHz FM
Searching... >
Volume
and the team bri
BBC Radio 2
'&$<7i
Cda]c^cd]T
'&$<7i

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PURE One Elite and is the answer not in the manual?

PURE One Elite Specifications

General IconGeneral
I/O ports1 x Mini USB
Audio systemstereo
DC-in requirements12V (0.8A)
Dimensions (WxDxH)256 x 88 x 155 mm
Power requirements230V AC
RMS rated power5 W
Radio typePortable
Tuner typeDigital
FM band range87.5 - 108 MHz
Supported radio bandsDAB
Radio Data System (RDS)Yes
Preset stations quantity50
Number of built-in speakers2
Display typeLCD
Product colorWhite
Volume controlRotary
Headphone connectivity3.5 mm
Battery typeC
Battery life (max)- h
Power consumption (standby)0.67 W
Power consumption (typical)2.46 W
