PureLink PT-C-HDSDI User Manual

User Manual
PT-C-HDSDI
5.Specications
Item Description
SDI standards 3G-SDI & HD-SDI & SD-SDI
Auto HD/SD-SDI detection Yes
Video bandwidth [2.97Gpbs & 2.975/1.001Gbps]
Video support
[3G] 1080p50/59.94/60 (4:2:2)
[HD] – 720p @50/59.94/60Hz,1080i @50/59.94/60Hz,
1080p @23.98/24/25/29.97/30Hz
[SD] – NTSC @59.94Hz, PAL @50Hz
Input signal HDMI
Output signal SDI
Output impedance 75Ω
Synchronization mode Internal synchronization or external synchronization
Eye pattern characteristics Extra low alignment jitter 0.05UI at HD
Cable equalization
[3G-SDI] up to 90m (300ft)
[HD-SDI] up to 150m (500ft)
[SD-SDI] up to 300m (1000ft)
Audio support Yes
PCB stack-up 6-layer board [impedance control — dierential 100Ω; single 50Ω]
Input 1x HDMI
Output
2x BNC [SDI]
BNC connector 75Ω inter-locked socket
HDMI Connector Type A (19-pin female)
Dimensions
73 x 84 x 24mm (L x W x H)
DIP switch 2-pin [for EDID use]
Mechanical
Housing Metal enclosure
Dimensions
[L x D x H]
Model 79 x 84 x 26mm [3.1” x 3.3” x 1.1”]
Package 140 x 200 x 75mm [5.5” x 7.9” x 3”]
Carton 420 x 400 x 300mm [1’8” x 1’4” x 11.8”]
Weight
Model 250g [8.8oz]
Package 780g [1.7 lbs]
Fixedness Inter-locked power supply
Power supply 5V 2A DC
Power consumption 3 Watt (max)
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH (no condensation)
4
