8. EDID Learning
9. Supported Resolutions
1. Please make sure the Pin#1-Pin#2 of DIP switch is at On-On [-].
2. Connect the HDMI display to the HDMI port of TX.
3. Power on TX.
4. After LED turns to light, the EDID Learning procedure is completed.
5. Please DO NOT change the DIP switch, otherwise the built-in EDID Learning information will be lost.
3G INPUT
1080p @ 50/ 59.94 / 60Hz SMPTE 424M, SMPTE 425M
HD INPUT
720p @ 50Hz SMPTE 296M -3
720p @ 60 / 59.94Hz SMPTE 296M -1, -2
1080i @ 50Hz SMPTE 274M -6
1080i @ 60 / 59.94Hz SMPTE 274M -4, -5
1080p @ 24 / 23.98Hz SMPTE 274M -10, -11
1080p @ 25Hz SMPTE 274M -9
1080p @ 30 / 29.97Hz SMPTE 274M -7, -8
3D INPUT
NTSC
PAL B,D,G,H,I
