Section 1: Getting Started
1.1 Safety and Notice
Please read all of these instructions carefully before you use the device. Save this manual for future
reference.
The PT-C-VGAHD VGA and Audio to HDMI™ Converter has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all electronic
equipments, the PT-C-VGAHD should be used with care. Please read and follow the safety instructions
to protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a stable
surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
1.2 Introduction
The PT-C-VGAHD VGA and Audio to HDMI™ Converter offers an easy and instant approach for converting
analog PC video (VGA) with either digital audio (S/PDIF) or analog stereo audio to digital HDMI. With this
module, VGA based devices such as PC with S/PDIF or analog stereo audio can readily connect to your
HDMI TV. With such a convenience, presentations, demonstrations, or digital signage become easier and
more cost effective.
— PC video supports up to UXGA (1600x1200) or WUXGA (1920x1200)
— Supports most popular VESA resolutions from 640x480 up to WUXGA
— Front panel LED indicators
— Easy installation The length depends on the characteristics and quality of the cables. Higher
resolutions and longer transmission distances require low skew cables (<25ns/100m) for best
performance. Unshielded CAT6 with metal RJ-45 connectors is recommended.
