PureLink PT-C-VGAHD User Manual

www.purelink.de
6
Section 2: Specifications
Item
Description
Units
PT-C-VGAHD
HDMI compliance
HDMI
DVI compliance
N/A
Video bandwidth
Single-link 165MHz [4.95Gbps]
Video support
Up to single link: 1080p@60, WUXGA [1920x1200@60Hz], UXGA
Audio support
Stereo audio
Input TMDS signal
1.2 Volts [peak-to-peak]
Input DDC signal
5 Volts [peak-to-peak, TTL]
PCB stack-up
4-layer board [impedance control — differential 100Ω; single 50Ω]
Input
1x VGA
1x RCA
1x 3.5mm
Output
1x HDMI
HDMI connector
Type A [19-pin female]
VGA connector
HD-15 [15-pin D-sub female]
RCA connector
Coaxial S/PDIF digital audio [PCM 48kHz]
3.5mm connector
Analog stereo audio
Control Switch
2-pin DIP switch
Environmental
Operating Temperature
0~40°C [32~104°F]
Storage Temperature
-20~60°C [-4~140°F]
Relative Humidity
20~90% RH (no condensation)
