DIRECT DIAGNOSTIC GUIDE
WIRE
COLOR
WIRE
GAUGE
CONNECT FROM CONNECT TO
Blue 10 Power In Input Source (+)
White 10 Ground Input Source (-)
White 8
Ground Liftgate
Battery (-) Fused
DC/DC Converter
Input Stud (-)
Yellow 16
DC/DC Converter
Ignition
DC/DC Converter
Ignition Stud
Black 8
Direct Controller
Power Out to DC/DC
converter
DC/DC Converter
Input (+)
Orange 14
Trailer Battery Sense
(Controller Power)
Postive Liftgate
Battery (+)
