3000 EXPRESS
Trim Tab Switch
Located in the helm. This switch controls the trim tab planes located on the transom of the boat. It
is protected by the 20-amp breaker. Please refer to Chapter 2 for detailed information on the
operation of the trim tab controls.
Accessory Switches (3)
These switches are supplied to protect additional equipment that may or may not have been installed
by Pursuit or your Pursuit dealer. If no accessories are activated by these switches, they remain
wired in the panel in reserve. Some accessories that may be connected to the accessory switches
are: The hardtop lights, battery parallel switch or electronics.
Additional Accessory Switch Panels
Additional switch panels are located in various locations in the cockpit and helm area of the boat.
Most of these panels are equipped with one switch and one circuit breaker. The following is a
description of additional panels that may be on your Pursuit and the accessories they control:
Baitwell Switch
Located under the gunwale in the cockpit. This switch activates the baitwell circulating pump that
supplies water to the baitwell. The pump is protected by a circuit breaker in the panel and an
automatically resetting breaker on the pump motor.
Washdown Pump
This switch activates the raw water washdown pump. The pump is the pressure demand type and
is protected by a circuit breaker in the panel and an automatically resetting breaker on the pump
motor.
Note: Please refer to the Raw Water System chapter for more information on the baitwell
and washdown systems.
FishBox Macerator Pump
The fishbox macerator switch panel is located in the rear of the cockpit near the transom door. It
is a momentary switch that activates the overboard macerator discharge system for the fishbox.
Windlass Switch
The windlass switch is located in the helm. This switch controls the optional windlass which is
mounted to the deck directly above the rope locker. It is protected by a circuit breaker of the type
and rating recommended by the windlass manufacturer.
12-Volt Receptacle
Provides electrical current for portable 12-volt equipment.
4-5
