PUSH PJS-350 - Exploded View

Push 67
EXPLODED VIEW
SPARE PARTS
REF. NR. DESCRIPTION PUSH NR.
8 + 9 SAW HOLDER 407866
6 - 11 SAW MECHANISM COMPLETE 407807
12 BUSHING 407862
13 GEAR 407861
14 SAW BLADE GUIDE 407860
16 INTERMEDIATE PLATE 407863
18 ROTOR 407864
19 + 21 CARBON BRUSH HOLDER 407800
20 CARBON BRUSH (SET) 407801
23 STATOR 407865
27 + 28 DUST ADAPTER 407809
29 SWITCH 407802
- SIDE GUIDE 407810
- ALLEN WRENCH 407850
Fig. 1 - Description
Fig. 2 - Types of saw blades
Fig. 3 - Assembling saw
Fig. 4 - Adjusting angle of bottom plate
Fig. 5 - Switch interlocking
Fig. 6 - Cutting in
2 Push
