18. Main technology data
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Main technology data
Frequency Range
Operating Temperature -20ºC+ 55ºC
Number Of Channel 16
Channel Spacing 12.5kHz
Operating Voltage 7.4V DC
Size 110mmX50mmX35mm(without antenna)
Weight About 226.7g(with battery)
Output Power
＜5W
Modulation Distortion
<=5%
Spurious Radiation <=7.5uW
Sensitivity <=-120dBm
Co-channel Rejection >=-8dB
Audio Distortion <=5%
138-174MHz
Analog:12.5kHz
Digital:6.25kHz
