Pyle PCA3 User Manual

FOREWORD
Your New Pyle Amplier gives you the power and versatility you need in a
professional sound system. The amplier's wide frequency response makes it
suitable for amplifying music or vocal program material. PCA3 is compatible
with walkman and computer devices and gadgets (MP3) via 3.5mm to RCA
converter.
Please read this manual thoroughly before you attempt to set up and use
the amplier. It contains a range of installation suggestions as well as
instructions to ensure safe usage.
Installed properly, you can expect years of trouble-free service from this
product.
FEATURES AND CONTROLS
FRONT PANEL
BACK PANEL
1. Power On/O and LED Indicator: Main power switch, the indicator lights
when the amplier is turned on
2. BLUE LED Output Level Display
3. Treble Tone Control: Lets you boost or attenuate treble, for the desired
sound
4. Bass Tone Control: Lets you boost or attenuate bass, for the desired sound
5. Master Volume Control: Lets you adjust the overall sound level
www.PyleUSA.com
2
www.PyleUSA.com
3
This product can expose you to a chemical or group of checmicals, which may include
“Nickel Carbonate” which is known in the state of California to cause cancer, birth defects,
or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
1
2
3 4
6
5
7 8 9
10 11 12
13 14 15 16

Pyle PCA3 Specifications

General

Amplifier class	-
Frequency range	20 - 40000 Hz
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	75 dB
Total Harmonic Distortion (THD)	0.3 %
RMS power output per channel (4 Ohm)	23 W
Line inputs (RCA)	2
Speakers connectivity type	RCA
Purpose	Home
On/off switch	Yes
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	120-230 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	137 mm
Width	190 mm
Height	73 mm
Weight	2285 g
