Pyle PCM20A User Manual

7 - Pyle Home PCM20A Manual
Specifications
Input Impedance
AUX........................................................200mV/50k-Ohm
MIC 1/MIC 2............................................1.0mV/600-Ohm
Max Output Power.........................................40 Watts x 1
THD at rated output power..................1% or less at 1 kHz
Frequency Response +/- 3 dB..................50 Hz to 15 kHz
Signal to Noise Ratio A-Weighted
MIC..........................................................................55dB
AUX..........................................................................70dB
Speaker Outputs.......... 8-Ohm, 25V, and 70V line outputs
Attenuation Level (MIC 1)..........................................40dB
Tone Controls
Treble.....................................................+/- 10dB, 10 kHz
Bass.......................................................+/- 10dB, 100 Hz
Power Requirement............120V AC 60Hz/230V AC 50Hz
Power Fuse......................T 1.2AL 250V for 110-120V and
T 0.63AL 250V for 220-240V
Dimensions, inches (mm) WxHxD..........7.87 x 3.15 x 5.90
(200 x 80 x 150)
Weight, lbs (kg) .................................................4.5 ( 2.04)
Specifications are typical; individual units might vary.
Specifications are subject to change and improvement without notice.

Pyle PCM20A Specifications

Power

max output power	40 Watts x 1
power requirement	120V AC 60Hz/230V AC 50Hz
power fuse	T 1.2AL 250V for 110-120V and T 0.63AL 250V for 220-240V

Audio Specifications

input impedance AUX	200mV/50k-Ohm
input impedance MIC 1/MIC 2	1.0mV/600-Ohm
THD at rated output power	1% or less at 1 kHz
frequency response	50 Hz to 15 kHz
signal to noise ratio MIC	55dB
signal to noise ratio AUX	70dB
speaker outputs	8-Ohm, 25V, and 70V line outputs
attenuation level MIC 1	40dB

Tone Controls

treble	+/- 10dB, 10 kHz
bass	+/- 10dB, 100 Hz

Weight and Dimensions

dimensions	7.87 x 3.15 x 5.90 inches (200 x 80 x 150 mm)
weight	4.5 lbs (2.04 kg)
