Setup and pairing (Wireless BT ampliers) are really easy. The following
instructions will help you connect Audio Ampliers to your music system or
pair with your tablet, computer, or smartphone.
1. Connecting the Speaker Wire
Audio stereo power ampliers that will power one pair of passive speakers
between 4 and 8 ohms (or subwoofer if you got the 2.1 CH amp or subwoofer
amp). To connect the amplier to your speakers you will need 2-conductor
stranded speaker wire. The ampliers use high-quality binding posts that will
accept heavy gauge bare wire banana plugs, spade lugs, or pin terminators.
If you use your own speaker wire we recommend using at least 16 gauge wire
and using the same length of wire from the amplier to each speaker It's also a
good idea to turn o your amplier before connecting power, audio sources or
speakers.
Preparing the Speaker Wire
1. Separate the last 3" of each speaker wire conductor.
2. Strip 1/2" of insulation from the end of each wire.
3. Twist the exposed copper strands with your ngers 3 or 4 times so the strands
stay together.
NOTE:
As you make your connections, be sure to connect the positive (+) terminals on
your amplier to the positive (+) terminals on your speakers. Even if your wire does
not have (+) or (-) markings, most 2-conductor speaker wire has printing on one
side to help you dierentiate between the wire pairs.
If you are Using Bare Wire
1. Use your thumb and nger to unscrew the binding post connectors on the back
of each speaker.
2. Insert each speaker wire into the holes on the side of the binding post connectors,
observing proper polarity.
3. Retighten the binding posts with your ngers.
4. The stripped portion of the wire should be secured rmly in each connector.
5. Make sure that none of the speaker wire strands have come in contact with an
adjoining terminal.
