Speaker Power Supply Connection:
The active speaker features the power supply for the speaker system. You
may choose to use the included power supply adapter to connect directly
into the active speaker's power supply input. *Optional power supply
connection can be made by directly 'hard-wiring' power supply cables to
the speaker's power supply screw terminal post -- as pictured, also located
on the active speaker.
www.PyleUSA.com
3
+
-
Plug-in Power
Adapter Input
*Optional Power
Source Input
Active Speaker
Passive Speaker
