Pyle PDMT25 - DC Voltage Measurement Specifications; AC Voltage Measurement Specifications

21
DC Voltage (Auto-ranging)
Range Resolution Accuracy
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
+
0.5% of rdg + 2 digits
1000V 1V +0.8% of rdg + 2 digits
Input Impedance: 7.8MΩ.
Maximum Input: 1000V dc or 1000V ac rms.
AC Voltage (Auto-ranging)
Range Resolution Accuracy
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
+
0.8%of rdg + 3 digits
1000V 1V +1.2%of rdg + 5 digits
Input Impedance: 7.8MΩ.
AC Response: 50 Hz 60Hz
Maximum Input: 1000V dc or 1000V ac rms.
DC Current (Auto-ranging)
