23
Resistance [Ω] (Auto-ranging)
Range Resolution Accuracy
400.0Ω 0.1Ω +0.8% of rdg + 5 digits
4.000kΩ 1Ω
40.00kΩ 10Ω
400.0kΩ 100Ω
+
0.8% of rdg + 2 digits
4.000MΩ 1kΩ
40.00MΩ 10kΩ
+
2.5% of rdg +8digits
Input Protection: 1000V dc or 1000V ac rms.
Capacitance (Auto-ranging)
Range Resolution Accuracy
4.000nF 1pF +5.0% of rdg+20 dgts
40.00nF 10pF +5.0% of rdg + 7 dgts
400.0nF 0.1nF
4.000uF 1nF
40.00uF 10nF
400.0uF 0.1uF
+
3.0% of rdg + 5 dgts
4.000mF 0.001mF
40.00mF 10.00mF
+
10% of rdg + 10 dgts
Input Protection: 1000V dc or 1000V ac rms.
