Pyle PDWM2120 User Manual

www.PyleUSA.com
3
PDWM4120 Receiver Front Panel
1. Wired Mic Input
2. Wired Mic Volume Controll
3. Wireless Mic A Volume Controll
4. Wireless Mic B Volume Controll
5. Wireless Mic C Volume Controll
PDWM4120 Receiver Back Panel
12 13 14 15 1611
1 2 3 4 5 6 7 8
9
10
6. Wireless Mic D Volume Controll
7. ECHO Knob
8. Music Volume Controll
9. RF LED indicator lights
10. AF LED indicator lights
11.3.5mm Audio Input
12.3.5mm Audio Output
13.1/4” (6.35mm) Audio Output
14.Power DC input
15.Power ON/OFF Switch
16.4 Antennas

Pyle PDWM2120 Specifications

General

Brand	Pyle
Model	PDWM2120
Category	Microphone system
Language	English
