Pyle PDWM2120 User Manual

www.PyleUSA.com
9
Wireless BT Streaming Connectivity:
• Simple & Hassle-Free Pairing
• Instant Wireless Audio Streaming Ability
• Play Music Directly from Your External Device
• Works with Smartphones, Tablets, Laptops, Computers
• Wireless BT Network Name: ‘Pyle’
• Wireless BT Version: 4.2
• Wireless Range: Up to 32’+ ft.
What's in the Box:
• Microphone Receiver Base
• (2) Wireless Handheld Microphones
• RCA-to-Aux (3.5mm) Cable, 4.6’ ft.
• Aux (3.5mm) Audio Cable, 3.3’ ft.
• 1/4'' -inch (6.3mm) Audio Cable, 3.3’ ft.
• USB Charge Cable
• Power Adapter
Technical Specs:
• Wireless Operation: UHF Band Transmitter
• Selectable Frequency Mic Design: 50 Channel
• Microphone Element/Type: Dynamic
• Pickup/Polar Pattern: Uni-Directional
• Wireless Operating Range: Up to 165'+ ft.
• Frequency Stability: <0.002%
• Sensitivity: 2/MV
• S/N Ratio: >95DB
• Transmitted Power: 10mW
• Dynamic Range: >95DB
• Distortion: <1%, 1kHz Modulation
• Frequency Response: 50Hz-18kHz (3±dB)
• Construction Material: Metal Alloy Receiver Base, Zinc Metal Mics
• Mic Rechargeable Battery: 3.7V Li-iOn, 1500mAh - 5.55Wh - 31.2g (Each)
• Power Supply: 120/240V (12V Power Adapter)
• Handheld Mic Size (L x W x H): 9.8’’ x 2.2’’ x 2.2’’ -inches (Each)
• Mic Receiver Base Size (L x W x H): 9.4’’ x 3.6’’ x 1.8’’ -inches

Pyle PDWM2120 Specifications

General

Brand	Pyle
Model	PDWM2120
Category	Microphone system
Language	English
