SystemInstallationandWiring
Note:CameraSysteminstallationondieselvehiclesmayrequireaslightlydifferentwiringinstall.
QuickInstallation:
This rearview backup camera system comes in two parts, one is the camera, the other is the monitor. When
installing,thecameracanbemountedeitherintherearofyourvehicle(preferablyjustabovethelicenseplate)
andhastwopossiblemountingoptions:flushmountorhangingmount.
Thiskitincludesnecessarywiringandcableconnectoraccessoriessufficientfortypicalconnections.
However,additional accessory cablesand installationmaterialsmaybe necessary for a completely
secureandoperationalbackupcameraperformance.
CameraConnection:
Connect the camera, using the red wire, of the included DC 12V power cable, to the positive 12V reverse tail
lightintherearofyour car.Then,connecttheblackwire,ofthe DC12V powercable,makingsureto ground
properly. This connected power and ground cable
then connects to the camera, and will supply power to the
cameradirectly.
Next, use the included yellow RCA video connector cable, and run that cable from the yellow RCA video
connectorjackofthecamera,totheyellowvideoconnectoroftheincludeddisplaymonitor.
DisplayMonitorConnection:
Connect
themonitor,usingtheredwire,oftheotherincludedDC12Vpowercable.Connectthiswiretoyour
vehicle'sfusepaneltoprovidepowertothemonitor.ThenconnecttheblackwireoftheDC12Vcablemaking
suretheconnectingisgroundedproperly.
The additional video input
on the monitor (white cable connector) is available for connecting an additional
monitorordisplayscreen.Theincludeddisplaymonitor assembly,whenconnected,automaticallyretrievesthe
videosignalwhenactivated.
Caution:Connecting to other types of electrical systems will cause damage to your vehicle. Please contact the manufacturer if you are
unawareofthesystemtypeinyourvehicle.Refertothemodel'spowerrequirementspriortoconnectionandinstallation.
