SystemInstallationandWiring
CameraSysteminstallationonvariousvehiclesmayrequireaslightlydifferentwiringinstall.Theseinstallationinstructionsdonotapplytoalltypesof
vehicles.Theyaremeantonlyasageneralguideduetothelargenumberofvehiclemakesandmodels.Consultyourlocalmotorvehiclelawsonthe
useofthisprod
uct
tobesureitispermitted.Throughinstallationofthisbackupcamerasystem,youshouldbesureastonotdegrade,damageor
compromisethesafetyofanysystemordeviceonyourvehicle.Improperinstallationandwiringofthevehicleback‐upcamerasystemmaydamage
the vehicle's elec
trical system, including vital vehicle computer and operating systems. That could lead to an accident or fire, causing property
damageand/orserious personalinjury.Itishighlyrecommendedtoseekprofessionalinstallationadvicefromaqualifiedautoelectricianor,inthe
alternative,tohavetheinstallationperformedbyaqualifiedaut
oelectrician.
PleaseensurethatyourmonitorassemblyissecuredandmountedwhereitwouldNOTobstructanyOEMvehiclesafetyfeatures.Inaneventofan
accident,themanufacturerisnotresponsibleforbodilyinjurycausedbythemonitorbeingaprojectile.Thisrearviewmirrorassemblysystemistobe
mounted over yo
u
r vehicle's existing rearview mirror. Ensuremonitor location will not obstruct your vision while driving. The system has a clamp‐
lockingmechanismwhicheasilyclampsoveryourvehicle'srearviewmirror.Themanufacturerassumesnoliabilityfordamagecausedtoyourvehicle
duetoimproperinstallationoruse.

QuickInstallation:
Thebackupcamerasystemiscompatiblewithawiderangeofvehiclesandvideodisplaymonitors.
(especiallysuitablefortheincluded rearviewmirrorandmonitorassembly.)
Thesystemincludes(2)DC12Vpowercables.
Thiskitincludesnecessarywiringandcableconnectoraccessoriessufficientfor typicalconnections.However,
additional accessory cables and installation materials may be necessary for a completely secure and
operationalbackupcameraperformance.
CameraConnection:
Connect the camera using one of the DC 12V power cables.Use the red wire to connect to the positive 12V
reversetaillightintherearofyourcar.Youmayneedtotemporarilyremoveaninteriorpanelorothercover.
Then,connect the blackwire of theDC 12Vpower cableand groundproperly.(Red wire is positive, black wireis
negative).
ThisDC12Vpowercableconnectstothecameraandwillsupplypowertothecameradirectly.Finally,
securetheyellowRCAvideoconnectionandruntheyellowvideocablefromthecameratotherearviewmirror
assembly. *Remember, connecting to the white video input of the mirror assembly will provide a picture only
whenthevehicleisplacedinreversegear.
RearviewMirrorMonitorAssemblyConnection:
ConnecttherearviewmirrormonitorassemblyusingtheotherDC12Vpowercable.Usethe redwiretoconnect
to your vehicle's fuse panel (preferably to the 12V ignition switch). You may need to temporarily  remove an
interior panel or other cover.Then, connect the black wire of the DC 12V power cable and ground properly.
ThisDC12Vpowercableconnectstotherearviewmirrormonitorandwillsupplypowertothecameradirectly.
Caution:Thisunitisdesignedtooperateon12VDCNEGATIVEGROUNDelectricalsystems.Connectingtoothertypesofelectrical
systemswillcausedamagetoyourvehicle.Pleasecontactthemanufacturerifyouareunawareofthesystemtypeinyourvehicle.
