INSTRUCTIONS
WIRING DIAGRAM
This player is equipped with ISO standard connector, please follow below instruction:
e Red - ACCON (129) e Grey/Grey back Right front speaker (/)
e Yellow -12 V Constant e Whine While Black - Left front speaker (+)
ө Black- Ground wire ө Purple/Purple black - Right rear speaker (+/-)
е Blue- Power Antenna / Remote Amp Tum On Green Green black - Let rear speaker (Р)
© Orange - Bade Up Camera Trigger (+) e Pink -Parking Brake ()
LN a:
