PLDN74BTi
MIC
IR
POWER MODE
VOL+ DN
UP
USB
Basic Operation
4
MIC
IR
POWER MODE
VOL+ DN
UP
USB
1 2 3 4 5 6 7 8 9 1110
1. Microphone window
2. Infrared window for remote control
3. Power on/off
4. Mode key
5. Ejecting disc
6. Volume decrease
7. Volume increase
8. Screen angle modulation
a. Press the key for a short time and the display will slide downward
b. Press the key for a long time and the display will slide downward to bottom.
9. Screen angle adjustment
a. Press the key to slide up the display
b. Press and hold the key and the display will slide upward to top
10. Reset key
11
. USB port
12. SD
card slot
13. GPS map card slot
(If equipped)
13
12
To Next Page
