Pyle PLMRA420 User Manual

14
15
high level mono input connections
4 ch amps PLMRA420
4 CH floating ground connections
4 CH harness wiring
for common ground connections
from speaker terminals
PLEASE NOTE! If using high level inputs, do not
use the low level RCA inputs at the same time!
R L
ORANGE
ORANGE
ORANGE
ORANGE
BLACK
BLACK
BLACK
BLACK
from speaker terminals
CH 1/2
CH 3/4
R L
ORANGE
ORANGE
ORANGE
ORANGE
BLACK
BLACK
BLACK
BLACK
Stereo Output Mode
Bridged Mono Output Mode
speaker connections
2 ch amps PLMRA220
speaker
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS!
PLMRA220
LEFT speaker RIGHT speaker
GROUND
+12V BATT
REM
FUSE
GROUND
+12V BATT
REM
FUSE
PLMRA420

Pyle PLMRA420 Specifications

General

Bass boost	0 - 18 dB
Amplifier class	A/B
Frequency range	15 - 30000 Hz
RMS rated power	250 W
Input sensitivity	250 mV
Audio output channels	4.0 channels
Peak power per channel	1000 W
Signal-to-Noise Ratio (SNR)	95 dB
RMS power output per channel (2 Ohm)	50 W
Audio (L/R) in	1
Speakers connectivity type	RCA
LED indicators	Power
Purpose	Boat
Product color	Blue, White
Volume control	Digital
Connectivity technology	Wired
DC input voltage	12 V
Power protection features	Overload, Short circuit

Weight and Dimensions

Depth	304.8 mm
Width	276.8 mm
Height	68.5 mm
Weight	4762 g
