Pyle PLPTS25 User Manual

1. Start by removing the end screws from the
two support bars.
2. Next, you will be connecting two of the L-
bars. Use one with rubber stoppers and one
without. Make sure that the two L-bars are
for the same side. The base and the
rubberized part of each respective L-bar
should be facing the same direction. Align the
L-bars so that at least two of their holes are
overlapping, and then insert two of the end
screws.
3. Now, flip this structure over and screw on
the two support bars.
4. Align the other two L-bars with the support
bars. Make sure that the two rubber stopper
L-bars are parallel and facing in towards each
other. The other L-bar should also be parallel
with its counterpart and facing inwards. Use
the remaining two end screws to secure this
mechanism into place.
5. Your stand is now complete!

Pyle PLPTS25 Specifications

General

Height adjustment	115 mm
Material	Metal
Product color	Black

Weight and Dimensions

Depth	247 mm
Width	235 mm
Height	277 mm
Weight	3630 g
