Pyle PMX401 User Manual

Pyle'PMX'SeriesMultiChannelMixers
 www.PyleAudio.com


MixerLayoutandControlsBackPanel
























16.
ACPOWER
ThepowersupplycableisthestandardvoltageforUSACwall
outlets.Itisgroundedandshouldneverhavethegroundpin
removedforanyreason.
17.
SPEAKEROUTPUTS
1/4''speakeroutputs(A/B).Standard2conductorphonejacks
arewiredinparallel,witheachhavingtheabilitytoconnectto
yourspeakersystem.
18.
EFFECTLOOP
Return:
Monounbalanced1/4''connectorjackforincorporatingreturn
effectorotherlinelevelsource.Itbringstheoutputofthe
externaleffectsdevicebackintothemixerforfurtherprocessing.
(Impedance:10KOhms@10dB).
Send:
Monounbalanced1/4''2Conductorlineoutputs.Usedto
connectadditionalrecordingdeviceorexternaleffectsprocessor.
Appliestotheinputofanexternaleffectsunitandallowsyouto
'send'yourdedicatedsignalouttotheconnectedexternal
device.(Impedance:1kOhm@10dB).
19.
POWERSWITCH
ControlthepoweroftheunitON/OFF.Whentheunitispowered
on,theLEDindicatorlightonthefrontwillshineblue.

Balancedvs.Unbalanced






Balancedlines are made specifically for reducingaudiointerference and noise rejection.  The rule ofthumb says, the longer thecable,the
morenoiseyouraudiosignalislikelytoencounter.Youraudiocableactsasanantennaandhastheabilitytopickupneighboringfrequencies,
andotherenvironmentalfactors,thatmayinterferewiththewayyoursoundperforms.The'noise'thatcanaffectyouraudiosignalsinclude
electromagnetic sound waves that are generated by devices like neighboring sound processors, computers, fans, motors, etc. Therefore,
balancedlinesarethebestoptionforrunninglongcablethroughyouraudioequipment.However,if
youraudioequipmentisconfinedwithin
a single room or small space, then unbalanced lines will function sufficiently; keep in mind, the less interfering electromagnetic wave
producing devices aroundyour equipment, the better. Balanced connector lines arealso widely used with microphone connection. The
outputsignalfrommostmicrophonesisrathersmall,soeventhesmallestamountofinterfering'noise'willbeevidenttoyourears.

Pyle PMX401 Specifications

General

Brand	Pyle
Model	PMX401
Category	Mixer
Language	English
