INTRODUCTION:
Pyle's PT506BT Desktop Audio Power Amplier is the perfect solution for all
of your audio needs. Using the latest sound amplication technology and an
impressive 200 Watt power output, this receiver is designed to deliver pure
stereo sounds from a wide range of connected music sources.
Built-in Wireless BT audio receiver ability allows you to stream your music
wirelessly and it works with all of your favorite devices (like Smartphones,
Tablets, Laptops, Computers, etc.). Enjoy full range stereo sound reproduction
when streaming audio with a wireless range of up to 30’ feet. Additional
system features include FM Radio with LCD display, USB Flash Drive Reader,
SD Card Reader, (2) 1/4" Microphone Inputs, Push Type Speaker Terminal
connectors, RCA Stereo Inputs, RCA Sub- woofer Output, and along with an
Aux (3.5mm) jack to connect even more external devices. Take control of
your sound with the Pyle PT506BT Desktop Audio Power Amplier.
Wireless BT Operation Instruction:
External devices which have a built- in Wireless BT feature can be connected
to this amplier wirelessly to play through the amplier’s speakers.
1. At rst be sure that the amplier is powered on, and turn the volume to the
MINI position. And it’s better to pull the Wireless BT Antenna on at the back
panel for better receiving.
2. Press the BT/Line button switch in on the front panel, you will hear the voice
“POWER ON” and also “PAIRING”, and then the unit is automatically ready to
pair with your external device.
3. Turn on the Wireless BT of your external devices like Smartphone, Computer,
and others, etc.
4. Search for available Wireless BT devices within range of your external device
and wait for your device to select “PYLEUSA” on the pairing devices lists.
5. And seconds later when you heard a voice “ Your Device is Connected”, then
the Wireless BT pairing is success.
6. You can now play music on your external device through the amplier.
Features and Controls:
FRONT PANEL
BACK PANEL
1. 1/4" MIC1 & MIC2 Input Jacks with Separate Volume Control
2. BT/USB/SD/FM/AUX Function Control
USB/SD ports and USB port doubles as device charge Port (5V/1A)
AUX: 3. 5mm AUX Input
MODE: BT/USB/SD/AUX/FM Switch
: Button Doubles as Previous Song and FM Frequency Down
: Button Doubles as Play/ Pause and FM Scan
: Button Doubles as Next Song and FM Frequency Up
REPEAT BUTTON: This button allows you to play the music in repeat mode
(All or Single mode)
ALL: All tracks in the USB or SD CARD will be repeated in order without
interruption.
SINGLE: Repeat the track that was currently playing.
11 12 13 14 15 16
1 2 3 4
567
10 9 8
