Front and Back Panel
1. Power ON/OFF Switch
2. Input select
3. Previous Song
4. Master Volume Controller
5. Play/Pause Function
6. Next Song
7. USB Reader
8. Blue LED Display Screen
9. CD/DVD Inputs (L/R)
10. CD/DVD Inputs (L/R)
11. Subwoofer Output
12. Speaker Output
13. Speaker Output
14. Cooling Fan
15. AC 120V/240V Input
16. 120V/240V Voltage Selector
