Pylontech US2000B User Manual

3
(d) Set the parameter according to below recommendation, the max. charge current refer
to the specific battery amount of real application. Then click ‘Apply’. According to the
inverter limitation, for 2kW&3kW inverter max. is 25A, for 5kW max. is 100A, for 10kW
max. is 200A.
2. WKS - Off-grid Solution
(1) General Compatible Condition:
Battery Type US2000B/Phantom-S
Inverter Type
WKS 1K-48 WKS 3K-48 WKS 4K WKS 5K
Max.
charge current
33A 33A 140A 140A
Recommend
battery Amount
According to load requirement and inverter rated power.
Battery Amount N = Load power/1200W
Communication Not required, but need finish the setting on Inverter.
DOD 80%
Working Temp. 0 - 50℃(Indoor operation)
Charge/Dischar
ge Current
N*25, N = Battery amount
Warranty 5yrs
