27
Pyromaster© H33BDVRRN/P
10004798
4. Pilot, Top Convertible SIT 10002266
* Pilot Orifice - SIT Top Convertible Nat. (not shown) 10002268
* Pilot Orifice - SIT Top Convertible Prop. (not shown) 10002269
5. Pilot Hood, SIT Top Convertible 10002385
6. Thermocouple, RN & RP 53373
7. Thermopile, RN & RP 51827
8. Pilot Tube w/fittings SIT 10001296
* Manifold Tube w/fittings (not shown) 57318
* Flexible Gas Line w/ ON/OFF Valve (not shown) 20002500
9a. Gas Valve Honeywell RN 10001782
9b. Gas Valve Honeywell RP 10001759
10. Fan Assembly w/bracket (FK24 Option) 54103
* Electrical Cord, (FK24 Option) (not shown) 51865
* Fan Temperature Sensor, (FK24 Option) (not shown) 51704
* Fan Speed Control, (FK24 Option) (not shown) 51738
* Knob, Fan Speed Control, (FK24 Option) (not shown) 51882
11. Fan Assembly, w/bracket (FK12 Option) ZA1110
12. Window Frame Assembly 10001803
*Window Glass w/Gasket (not shown) 10002822
* Gasket (Window Glass) (not shown) 57317
13. Clamp, Window Frame Assembly 54174
14. Window Trim, Polished Brass w/magnets 55005
15. Top Louvre Assembly 10000292
16. Bottom Louvre Assembly 10000293
17. Hinge (Bottom Louvre Assembly) 53256
* Restictor Plate (not shown) 10002495
* Remote ON/OFF Switch 51842
* Remote Switch it (Switch, Wire & Bracket) 53875
18. Relief Plate w/Gasket Assy. Burner Tray 10004192
* Conversion Kit RN to RP (not shown) 10004800
H33BDVRRN/P (continued)
Ref. Description Part Number
