Pyronix Enforcer 32WE User Manual

The Enforcer control panel has numerous design features that allow for a quick and easy
installation:
1. Fix the back casing to the wall.
2. Wire the mains cable to the mains terminal connectors and connect
the telephone line if Digi 1200 is used or connect Digi GSM.
3. Ready to program.
2 wired inputs,
3 programmable outputs,
RS485 bus interface
RS232 connection for
local programming
via UDL software
2.2 Amp
Back up battery
Front Tamper
Hinged Front
Panel
Rear Wall
Tamper
PSU unit location
220V
Mains Input
Two digital
communicators
available:
DIGI-1200
Fast PSTN Digital
communicator
DIGI-GSM
GSM Digital
communicator
1,2,3 Step Friendly Installation

Pyronix Enforcer 32WE Specifications

General

Panel Type	Hybrid
Zones	32
Wireless Zones	32
Keypads	Up to 4
Areas	4
Battery Backup	Yes
Mobile App	Yes (PyronixCloud)
Weight	1.5 kg
Operating Temperature	-10°C to +40°C
Type	Wireless
Communication	GPRS
Outputs	Programmable outputs
Power Supply	230VAC
Humidity	85% RH non-condensing
