Q'STRAINT QRT-1 Series Use And Care Manual

6
EQUIPMENT
Functionality of Q’Straint® Manual Tiedown Straps
1
4
1
3
2
2
4
3
2
3
4
1
Q5000 REAR TIEDOWN
Q5000 FRONT TIEDOWN
M-SERIES FRONT & REAR TIEDOWN
1. Anchorage
2. Webbing Loop
3. Adjuster
4. Hook
5. Shoulder Belt Pin Connector
1
2
4
5
1. Red Release Lever
2. Connecting Pin on Retractor
(for occupant restraint)
3. Frame and cover
4. Webbing
5. J-Hook
(universal wheelchair securement)
6. Retractor Knobs
(manually tension webbing)
Functionality of Q’Straint® Retractors
3
6
5

Q'STRAINT QRT-1 Series Specifications

General

Brand	Q'STRAINT
Model	QRT-1 Series
Category	Wheelchair
Language	English
