Q-SYS SPA-Qf Series User Manual

11
Connections
Wire
Strip length = 5mm. DO NOT TIN!
IMPORTANT: Class 2 Wiring.
5mm
1:1
Output Connectors
SPA-Qf 2-Channel SPA-Qf 4-Channel
Flex Connectors
Balanced Unbalanced
CAUTION! A single channel consists of three
pins. It is possible to plug in a connector that
straddles two channels. Be sure that the plugs
do not straddle two channels.
