AP4
+
B
Specifications - Bottom Inlet, Long
AP4
+
AutoPum
p
Air Supply
Exhaust
Liquid Discharge
Actuation Level 38.4" (98 cm)
Length with Extended Screen Attached 51.4" (131 cm)
Inlet
O.D. 3.6" (91 mm)
Application Limits (Base model)
AP4+ AutoPumps are designed to handle
the application ranges described below.
For applications outside these ranges,
consult QED about AP4+ upgrades.
Maximum Temperature: 180°F (82°C)
pH Range: 4-9
Solvents and Fuels: diesel, gasoline,
JP1-JP6,#2 heating oils, BTEX, MTBE,
landfill liquids
*Consult QED for higher flow requirements
Material upgrades available
Applies to QED supplied tubing;
other tubing sources may not
conform to QED fittings.
1
2
4" - Long AP4+ Bottom Inlet
Bottom
3.6 in. (91 mm)
51.4 in. (131 cm)
16.7 lbs. (7.6 kg)
14 gpm (53 lpm)* - See Flow Rate Chart
0.58 - 0.78 gal (2.2 - 3L )
38.4 in. (98 cm)
250 ft. (76 m)
5 - 120 psi (0.4 - 8.4 kg/cm2)
0.4 - 1.1 scf / gal. (3.0 - 8.5 liter of air /
fluid liter) - See air usage chart
425 ft. (130 m)
5 - 200 psi (0.4 - 14.1 kg/cm2)
0.7 SpG (0.7 g/cm3)
Fiberglass or Stainless Steel
Stainless Steel
Stainless Steel, Viton, PVDF
³, Hastelloy-C
Brass or Stainless Steel
Barbs, Quick Connects or Easy Fittings
Nylon
1 in. (25 mm) or 1-1/4 in. (32 mm) OD
1/2 in. (13 mm) OD
5/8 in. (16 mm) OD
Nitrile
3/4 in. (19 mm) or 1 in. (25 mm) ID
3/8 in. (9.5 mm) ID
1/2 in. (13 mm) ID
Model
Liquid Inlet Location
O.D.
Overall Length With Extended Screen
Weight
Maximum Flow Rate
Pump Volume/Cycle
Minimum Accuation Level
Standard Pump
Maximum Depth
Air Pressure
Air Usage
Maximum Depth
Air Pressure
Minimum Liquid Density
High Pressure Pump
Standard Construction Materials¹
Pump Body
Pump Ends
Internal Components
Tube & Hose Fittings
Fitting Type
Tube & Hose Options
Tubing Materials²
Sizes - Liquid Discharge
Pump Air Supply
Air Exhaust
Sizes - Liquid Discharge
Pump Air Supply
Air Exhaust
Hose Material
Specifications & Operating RequirementsPump Dimensions
Long and short AP4+ AutoPumps are warranted for
five(5) years: Low-Drawdown AP4+ AutoPumps are
warranted for one (1) year.
