Qilin Laser Application Technology BWT20 - Welding Head and Trigger Interfaces

BWT20 Qilin double swing handheld laser
welding
system
user
manual
V1.0
137/24
on
1 24V Power supply
output, 500 mA
HMI supply electricity
2
GND Power supply output
ground
Power reference
3 T XD The sender of the
HMI
Serial port communication with the
TXD signal
4 RXD The receiving end
of the HMI
Serial port communication with the
RXD signal
2.6 Double swing handheld laser welding head interface
The motherboard provides a vibrating scope interface, compatible with the
common digital lens interface on the market,
Table 2.6 shows the definition of the vibration scope interface.
Table 2.6
pin signal defi
niti
on
expl
ain
1 DB15 Vibrator scope & OLED interface
Control line for communication
with the hand-held welding head
2.7 Lead the trigger line
The control box provides a special security trigger signal line interface, which can
provide a security guarantee for the operation.
Table 2.7 defines for the safety clip interface.
