5.3. GENERAL OPERATION
7
Floor brush
The brushes of the oor brush (16) can be adjusted according
to the oor type to be cleaned (Fig. 7).
■ Press
on the Floor brush switch (17) to extract
the brushes when cleaning hard oors that are not
susceptible to scratching.
■ Press
on the Floor brush switch (17) to retract the
brushes when cleaning carpets, rugs or hard surfaces.
8
5
Suction power selector
■ To adjust the suction power, slide the Suction power
selector (4) left/right to the desired level (Fig. 8).
– Minimum: For delicate materials, curtains.
– Medium: For furniture, rugs and mattresses.
– Maximum: For tiles, wooden or other hard oors.
9
Extra suction power switch
■ When it is dicult to move the oor brush (16) over
the oor, you can also adjust the suction power with
the Extra suction power switch (12) on the handle of
the suction hose (Fig. 9). Slide the button up/down to
adjust.
10
Parking the telescopic tube with the oor brush
There are two slots for parking. One located on the bottom of
the vacuum cleaner and the other on the back. This feature
allows you to park the telescopic tube (14) with the oor
brush (16) in one of the parking positions during pauses or
storage.
■ Press the Telescopic tube release button (15) to retract
the tube before parking.
■ Horizontal parking position – Slide the tab on the
neck of the oor brush (16) into the parking slot on the
back of the vacuum cleaner as illustrated (Fig. 10).
■ Vertical parking position – Stand the vacuum cleaner
upright and slide the tab on the neck of the oor brush
(16) into the parking slot on the bottom of the vacuum
cleaner as illustrated (Fig. 10).
