Qlima PGP 113 - Page 3

PICTURES
PARTSLIST
Picture 1 Picture 2
Part No. Part name QTY Pictures
1 FR: Plaque intermé-
diaire
GB: Middle plate
IT: Piastra centrale
NL: Midden plaat
1
2 FR: Boîtier de com-
mande
GB: Control box
IT: Pannello di con-
trollo
NL: Behuizing rege-
ling
1
FR: Pré-assemblage
dans la plaque
intermédiaire (1)
GB: Preassembled
in middle plate (1)
IT: Preassemblato
nella piastra cen-
trale (1)
NL: voor geassem-
bleerd in midden
plaat (1)
3 FR: Plaque inférieure
GB: Bottom plate
IT: Piastra di fondo
NL: Onderplaat
1
4 FR: Support inférieur
GB: Lower support
IT: Supporto inferiore
NL: Hoek profiel –
laag
4
5 FR: Support supérieur
GB: Upper support
IT: Supporto superi-
ore
NL: Hoek profile –
hoog
4
Picture 1a
Front
Back
Front
Back
