G UNIT PARTS
NOTE: The installation must be performed in accordance with the requirement of local and national
standards. The installation may be slightly different in different areas.
1. Wall Mounting Plate 5. Functional Filter (On Back of
Main Filter - Same Units)
9. Remote Controller
2. Front Panel 6. Drainage Pipe 10. Remote controller Holder
(Some Units)
3. Power Cable (Some Units) 7. Signal Cable 11. Outdoor Unit Power Cable
(Some Units)
4. Louver 8. Refrigerant Piping
G
NOTE ON ILLUSTRATIONS
lllustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly different. The actual shape shall prevail.
H INDOOR UNIT INSTALLATION
lnstallation lnstructions - Indoor unit
Prior to installation
Before installing the indoor unit, refer to the label on the product box to make sure that the model
number of the indoor unit matches the model number of the outdoor unit.
Air-break switch
4
