3 – Managing Fabrics
Zoning
3-22 59264-01 A
S
Create Alias button — creates another name for a set of objects
Add Member button
— adds selected port/device to a zone
Remove Member button — deletes the selected zone from a zone
set, or delete the selected port/device from a zone
Copy button
— copies selected zoning items to clipboard.
Paste button — pastes clipboard items to selected zoning item
where applicable.
Switch port icon
— not logged in
Switch port icon — logged in
NL_Port (loop) device icon
— logged in to fabric
NL_Port (loop) device icon — not logged in to fabric
N_Port device icon
— logged in to fabric
N_Port device icon — not logged in to fabric
Table 3-3. Edit Zoning Dialog Tool Bar Buttons and Icons (Continued)
Button/Icon Description
