No. Component No. Component
1 Drive status LED 4 10 Gigabit Ethernet speed LED
2 Drive activity LED 5 2.5 Gigabit Ethernet activity LED
3 10 Gigabit Ethernet activity LED 6 2.5 Gigabit Ethernet speed LED
LED Status Description
Drive status Green The drive is ready.
Red A drive read/write error occurred.
Flashes red every 5 seconds A drive is being located in the
operating system.
Off • No drive detected.
• The drive is not initialized.
Drive activity Green The drive is ready.
Flashes green The drive is being accessed.
Off No drive activity has been
detected.
10 Gigabit Ethernet port speed Green The network connection is
operating at 10 Gbps.
Off The network connection is not
operating at 10 Gbps.
10 Gigabit Ethernet port activity Orange The network link is active.
Flashing orange The data is being transmitted.
Off There is no network link.
2.5 Gigabit Ethernet port speed Green The network connection is
operating at 2.5 Gbps.
Orange • The network connection is
operating at 1 Gbps.
• The network connection is
operating at 100 Mbps.
Off The network connection is
operating at 10 Mbps.
2.5 Gigabit Ethernet port activity Orange A network connection has been
established.
Flashes orange The NAS is being accessed from
the network.
Off There is no network connection.
Storage Node Power Button
Operation User Action Result
Power on Press and hold the button for 1.5
seconds.
• The OLED panel turns on.
• The node powers on.
Power off Press and hold for 5 seconds. The node powers off.
GM-1000 User Guide
Product Overview 16
