10W HF Linear PA kit assembly 1.00 5
R205 2.2K, red-red-black-brown-brown
R213, 218 10K, brown-black-black-red-brown (2pcs)
R212, 214 47-ohm, yellow-purple-black-gold-brown (2pcs)
R207, 208 2.2-ohm, red-red-black-silver-brown (2pcs)
R206 33-ohm, orange-orange-black-gold-brown
R211, 215 4.7K trimmer potentiometer, label “472” (2pcs)
Capacitors
C201 - 203, 205 - 210, 215 0.1uF, code “104” (10pcs)
C204 10uF 25V electrolytic
C214 470uF 25V electrolytic
C211, C212 1uF, code “105” (2pcs)
C213 33pF, code “330”
Semiconductors
D201 1N4004
Q201 2N3904
Q203, 203, 204, 205 BS170 (4pcs)
Q206, 209 IRFU9024, substitute for BS250 (2pcs)
Q207, 208 IRF510 (2pcs)
IC201 78L05, 5V voltage regulator
Inductors
L201 BN43-2402 binocular core
L202, L203, L204, L205 1uH molded axial inductors
T201, 202 BN61-2402 binocular core (2pcs, separate bag)
T203 FT50-43 toroidal core
T204 BN43-202 binocular core
Miscellaneous
PCB PCB
Insulated wire 30cm of insulated wire
0.6mm wire 80cm of 0.6mm enamelled wire
0.4mm wire 15cm of 0.4mm enamelled wire
0.25mm wire 60cm of 0.25mm enamelled wire
Insulating silicone pad Insulating heatsink silicone pad (3pcs)
M6 nut M6 nut
Washer Large washer
Insulating washer 2pcs white plastic insulating washer
9mm M3 bolt 9mm M3 bolt
15mm M3 bolt 15mm M3 bolt
Rubber tube Short ~4mm length of rubber tube
Heatsink Custom-manufactured 130x28x25mm
