Capacitors (50V, Multi-layer Ceramic capacitors except where indicated otherwise)
(see below for listing of band-version dependent inductors)
Qty Value Description Component numbers
15 2.2u SMD 0603
C101，C102，C103，C104，C105，C215，C216，
C406，C407，C408，C413，C414，C430，C434，
C510
2 470u 6.3V tantalum C106, C107
32 0.1u SMD 0603 C201,C202,C203,C204,C206,C207,C208,C209,C210,
C211,C212,C214,C217,C219,C301,C409,C410,C415,
C428,C429,C436,C438,C501,C503,C507,C508，C50
9，C513，C526，C527，C528，C529
3 47n SMD 0603
C205，C411，C412
3 1u SMD 0603
C213，C405，C506
3 1n SMD 0603
C218，C220，C505
4 33n SMD 0603
C416，C417，C418，C419
3 10u SMD 0805
C420，C421，C502
4 4.7n SMD 0603
C422，C423，C424，C425
2 10n SMD 0603
C426，C427
4 10u Tantalum case A style
C431，C433，C435，C439
2 1u Tantalum case A style
C432，C437
1 470u Electrolytic 10V C504
2 47p SMD 0603
C511，C512
Semiconductors
Qty Description Component numbers
9 SMD: 1N4148 SOD323
D101，D102，D103，D104，D105，D501，D505，
D506，D507
5 SMD: SS14 DO-214AC
D106，D107，D502，D514，D515
6 1N4007 diode D508, D509, D510, D511, D512, D513
2 Unused diode D503, D504
1 SMD: 5.6V 500mW SOD-123 D108
1 SMD: 3.6V 500mW SOD-123 D109
1 SMD: 78M05 TO252 IC101
1 SMD: 24M01 SOIC-8 IC201
1 SMD: SN74AHC1G00DBV IC202
1 SMD: STM32F446VET6 IC203
1 SMD: MS5351M IC204
1 SMD: CS4334 SOIC-8 IC401
2 SMD: 74CBT3253 SOIC-16 IC402, IC403
1 SMD: NE5532 SOIC-8 IC404
2 SMD: LM4562 IC405, IC406
1 SMD: PCM1804 IC407
QMX assembly Rev 1.00e 18
