Qty Description Component numbers
2 SMD: 74AHC1G86DBV IC501, IC502
1 SMD: 74ACT08 SOIC-14 IC503
4 SMD: BSS84 MOSFET
Q102，Q202，Q204，Q502
12 SMD: BSS123 MOSFET
Q101，Q104，Q106，Q107，Q110，Q203，Q301,
Q501，Q508，Q509，Q510，Q511
5 SMD: BC817 NPN SOT23-3
Q12，Q13，Q14，Q112，Q113
2 SMD: BC857 PNP SOT23-3
Q15，Q16
4 BS170: TO92 MOSFET Q503, Q504, Q505, Q506
3 SMD: AO3415A SOT23-3
Q108，Q109，Q111
3 SMD: AOD403 (TO252)
Q103，Q105，Q507
1 SMD: 25MHz TCXO module TCXO
Inductors
(see below for listing of band-version dependent inductors)
Qty Description Component numbers
5 SMD: 47uH L2012
L201，L202，L402，L503，L504
3 SMD: 330uH (CD54)
L101，L102，L501
4 47uH axial inductor L505, L507, L509, L514
2 FT37-43 L502, T401
1 BN43-202 binocular, 3:3 T501
1 BN43-1502 binocular T507
Miscellaneous
Qty Value Description
1 2.1 mm DC 2.1 x 5.5 barrel DC power connector
1 USB C USB type C connector
1 BNC Metal RF connector
3 3.5mm jack 3.5mm Stereo connector (PTT)
2 2x4 Pin header connector socket (female)
1 2x4 Pin header connector 90-degree plug (male)
1 2x3 Pin header connector socket (female)
1 2x3 Pin header connector 90-degree plug (male)
1 2x5 Pin header connector socket (female)
1 2x2 Pin header connector socket (female)
1 2x4 Pin header connector 17mm long plug (male)
1 2x2 Pin header connector plug (male)
1 2x5 Pin header connector plug (male)
1 PCB Main PCB, 92 x 139.4 mm
1 1602 LCD 80x36mm HD44780 LCD module yellow/green
QMX assembly Rev 1.00e 19
