Qty Value Description
1 6mm Electret Microphone
2 Rotary Rotary encoder switch
2 6x6x8mm Push-button switch
2 15mm Knob
1 365 cm (80-20m version) 0.33 mm diameter wire (AWG #28)
(varies depending on QMX version as noted)
1 65 cm (80-20m version) 0.60 mm diameter wire (AWG #22)
(varies depending on QMX version as noted)
1 M3 12 mm Steel 12mm long M3 screw
1 M3 Steel M3 nut
1 M3 12 mm Steel 12mm diameter M3 washer
5 M3 x 11mm Nylon threaded hex spacer
12 M3 x 6mm Nylon screw
2 M3 x 9mm Nylon screw
6 M3 Nylon nut
Enclosure (OPTIONAL)
Qty Value Description
1 Top Extruded aluminium top, cut, drilled and laser-etched
1 Bottom Extruded aluminium bottom
1 Left panel Laser etched, drilled for three connectors
1 Right panel Laser etched, drilled for three connectors
8 M2.5 machine screw Screws to secure end panels
4 Rubber foot Self-adhesive rubber foot
QMX assembly Rev 1.00e 20
