QRP Labs QMX Assembly Manual

Frequency dependent parts:
80 / 60 / 40 / 30 / 20m version of QMX:
Capacitors (50V, Multi-layer Ceramic capacitors):
Qty Value Description Component numbers
1 22pF Label “220” C403
1 30pF Label “300” C401
2 56pF Label “56J” C521, C404
1 82pF Label “820” C522
1 100pF Label “101” C520
1 180pF Label “181” C525
1 220pF Label “221” C402
1 270pF Label “271” C516
2 390pF Label “391” C515, C524
2 470pF Label “471” C523, C519
2 820pF Label “821” C518, C514
1 1200pF Label “122” C517
Inductors (powdered iron Micrometals toroids):
Qty Description Component numbers
1 T30-6 toroid (yel), 2.40 uH (26t) L511
1 T30-6 toroid (yel), 2.88 uH (28t) L506
1 T30-6 toroid (yel), 1.06 uH (17t) L512
1 T30-6 toroid (yel), 394 nH (10t) L513
1 T30-6 toroid (yel), 1.20 uH (18t) L508
1 T30-6 toroid (yel), 525 nH (12t) L510
1 T50-2 toroid – tapped, see text L401
QMX assembly Rev 1.00e 21
