4
EN
ES
FR
DE
CH
ON
POWER
P
POWERLIGHT 3
PL380
8000 WATT POW ER AMPLIFIER
MODEL NUMBER
PL325, PL340, PL380
RACK MOUNTING EAR
2RU, fits #10-32 or M6.
AC POWER SWITCH
Relay Controlled Inrush Limiting
COOLING VENTS
Rear-to-Front Air Flow. Keep Clear.
OPTIONAL HANDLES
See page 8 for Installation.
ON
POWER
P
POWERLIGHT 3
PL380
8000 WATT POW ER AMPLIFIER
MODEL NUMBER
PL325, PL340, PL380
RACK MOUNTING EAR
2RU, fits #10-32 or M6.
AC POWER SWITCH
Relay Controlled Inrush Limiting
COOLING VENTS
Rear-to-Front Air Flow. Keep Clear.
OPTIONAL HANDLES
See page 8 for Installation.
