QSC TouchMix-16 User Guide

63
TD-000472-00-B
Phones and Monitor
Controls the output level for the Phones Cue and Monitor Cue
Press
Phones
OR
Phones M onitor
Press
Monitor
NOTE: Refer to — Figure 66
NOTE: The Monitor Level control is available only on the
TouchMix-16.
Phones (1) and Monitor (2) Level – Controls the level of the Cue signal on
the Phones and Monitor outputs.
NOTE: By default, no audio signal is sent to the Phones /
Monitor Outputs. To send audio channel signals (including Main
LR) to the Phones / Monitor Outputs. Enable the Cue button for
the channels you want to listen to.
— Figure 66 —
1
2

QSC TouchMix-16 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
XLR out	8
DJ mixer	-
Audio input	4x XLR/TRS combo, 12x XLR, 2x TRS
Product color	Silver

Weight and Dimensions

Depth	291 mm
Width	360 mm
Height	58 mm
Weight	2980 g
