Mutes
The TouchMix has a sophisticated and powerful Mute system. In addition to the Mute Groups (See "Mute Groups" on page 6) inputs and
individual channel sends to individual aux mixes may be muted independently.
Main Mutes: When a channel is muted while the Main L/R is selected, the channel is also muted to all Auxiliary and FX mixes. This is true whether
the channel was muted using the channel Mute button or a Mute Group.
Auxiliary Mutes: It is sometimes useful to mute an individual input to only one auxiliary mix. When an Auxiliary is selected by touching one of the
buttons on the left of the screen, the Mute button that is displayed with the channel faders will effect only the selected auxiliary mix.
The Mute buttons have three states…
•
Mute
: Indicates the channel is not muted.
•
Mute
:
» With Main L/R mix selected, indicates that the channel has been muted by pressing the channel Mute button. The
channel’s signal is also muted for all auxiliary sends.
» With Auxiliary mix selected, indicates that the channel is muted for the currently selected Auxiliary mix. This affects
only the muted channel and only for the selected Aux mix.
•
Mute
:
This is an indication that the channel is muted by something other than the Mute button you’re seeing.
» With Main L/R mix selected, indicates that the channel is muted from a Mute Group, or DCA Group*.
» With Auxiliary mix selected, indicates that the channel is muted from a Mute Group, DCA Group or at the Main L/R
mix.
» For FX Returns, indicates that the channel is muted from a Mute Group, DCA Group or FX Mute button
NOTE:
*A DCA mute will not mute an auxiliary send that is set to a pre-fader pick-off point.
