Qsonica Sonicator User Manual

Rev. 3-11
16
Pulse on -- sec
Pulse off --sec
Pulse on 01 sec
Pulse off -- sec
Pulse on 01 sec
Pulse off 01 sec
Time 0:30:00
Pulse 01 01 Ampl 40 %
PULSER: Ultrasonics generates heat. Pulsing ultrasonics on and off helps to prevent heat
build up in temperature sensitive samples. In addition, pulsing enhances processing by allowing
the material to settle back under the probe after each burst. The ON and OFF pulse duration
can be set independently from 01 second to 59 seconds. During the OFF portion of the cycle,
the red indicator on the PULSE key will illuminate. If the OFF portion of the cycle exceeds three
seconds, a cautionary message - Sonics in OFF Cycle - will warn the operator against touching
the ultrasonic probe.
1. To set the pulser, press PULSE key.
The screen will display:
2. Using the numeric keys, set the ON portion of the cycle, and press the ENTER/REVIEW key.
The screen will display:
3. Using the numeric keys set the OFF portion of the cycle.
The screen will display:
4. Press the ENTER/REVIEW key.
The screen will display:
On Cycle Off Cycle

Qsonica Sonicator Specifications

General

Frequency	20 kHz
Amplitude Range	20-100%
Pulse Mode	Yes
Display	Digital
Probe Diameter Options	1/2", 3/4"
Voltage	110V or 220V
