QXPA
Portable PA Units
Order ref: QX12PA (178.853UK)
QX15PA (178.856UK)
User Manual
VERSION 1.0

Table of Contents

Questions and Answers

  • B
    Brooke AllenAug 1, 2025
    What to do if the power LED is lit but there is no USB/SD player output on my Qtx QXPA?
    • G
      grayjuliaAug 1, 2025
      If the power LED is lit but there's no output from the USB/SD player on your Qtx Speaker System, here are some things to check: * Ensure the USB or SD card contains the correct audio files. * Verify that the USB or SD card is properly connected. * Try pressing the MP3/LINE button, then the >II button. * Make sure the volume isn't turned down. * Press and hold the “VOL +” button. * Check the LCD display to see if the numbers are moving.
  • M
    matthewhornAug 7, 2025
    What to do if the power LED is lit but there is no sound from external inputs on my Qtx QXPA?
    • J
      Joshua MatthewsAug 7, 2025
      If the power LED is lit but you're not getting any sound from external inputs on your Qtx Speaker System, try the following: * Check that the connecting leads are working and properly connected. * Verify the volume and on/off switch on the external microphone or line source. * Ensure that neither the VOLUME nor MIC VOLUME control is turned all the way down. * Confirm that "LINE IN" is displayed on the LCD for the AUX input by pressing the MP3/LINE button.
  • T
    Timothy CruzAug 14, 2025
    What to do if the power LED is lit but there is no VHF output on my Qtx QXPA?
    • M
      Michael ReidAug 14, 2025
      If the power LED is lit but there's no VHF output from your Qtx Speaker System, consider the following: * Check the 9V batteries in the wireless transmitters. * Ensure the wireless transmitters are switched on. * Verify that the VHF POWER is switched on. * Make sure the MIC VOLUME isn't turned down. * Check the RF A and RF B LEDs for a radio signal.
  • L
    lynchbenjaminAug 19, 2025
    How to troubleshoot no output and no LEDs lit on a Qtx Speaker System?
    • R
      Robert HamptonAug 19, 2025
      If there is no output and no LEDs are lit on your Qtx Speaker System, please check the following: * Ensure the POWER switch is turned on. * Verify that the battery is not completely drained. * Confirm that the mains lead is properly connected. * Check that the mains or D.C. fuse hasn’t blown.
  • J
    Jeremy SinghAug 26, 2025
    Why does the music level keep cutting out on my Qtx QXPA Speaker System?
    • T
      Tiffany SteinAug 26, 2025
      If the music level is off or keeps cutting out on your Qtx Speaker System, ensure that VCV is not switched on, as it will mute the music upon receiving a microphone signal.

Summary

Introduction and Safety Precautions

Product Introduction

Overview of the QXPA portable PA unit and its applications.

Package Contents Checklist

Ensuring all accessories are received in good condition upon purchase.

Important Warnings

Safety warnings regarding fire, electric shock, and user serviceability.

General Safety Guidelines

Recommendations for safe operation, including power connection and avoiding water ingress.

Optimal Placement and Environment

Advice on positioning the unit away from heat, sunlight, and moisture.

Cleaning and Maintenance

Instructions on how to clean the unit safely using appropriate materials.

Unit Controls and Operation

Audio Input and Volume Controls

Controls for master volume, bass, treble, microphone volumes, and Bluetooth volume.

Media Player and Connectivity

Controls and ports for USB, SD, FM player, Bluetooth, and line inputs/outputs.

Microphone Specific Controls

Controls for VCV, microphone contour, echo, and delay effects.

Power and Indicator Status

Power switch, LEDs, mains inlet, DC input, and fuses for power management.

Microphone and Input Setup

VHF Wireless Microphone Setup

Instructions for setting up VHF microphones, including antenna extension and battery insertion.

Feedback Prevention and Effects

Guidance on avoiding feedback and using echo/delay effects for vocals.

Microphone Tone Adjustment

Using the CONTOUR, BASS, and TREBLE controls to shape microphone sound.

External Input Connections

Connecting wired microphones, line sources via RCA/3.5mm, and using the line output.

Media Player and Bluetooth

Internal Media Player Operation

Guide to playing audio from USB, SD card, or FM radio.

Media Player Controls Explained

Explanation of the panel buttons for playback, navigation, and recording.

Remote Control for Media Player

Using the infra-red remote for enhanced control over the media player.

Bluetooth Connectivity Guide

Pairing Bluetooth Devices

Step-by-step instructions for pairing smartphones or audio players via Bluetooth.

Bluetooth Audio Playback

Managing audio playback and volume from a connected Bluetooth device.

Remote Playback Functionality

Using the unit's button to pause or resume playback on the source device.

Bluetooth Range and Limits

Information on operational range and single-device pairing for Bluetooth connections.

Specifications and Troubleshooting

Technical Specifications

Detailed technical specifications for QX12PA and QX15PA models.

Troubleshooting No Output

Solutions for units with no power or audio output.

Troubleshooting VHF Microphone Issues

Resolving no sound from wireless mics or weak RF signal problems.

Troubleshooting Audio Level Problems

Fixing issues with music volume cutting out or being too low.

Troubleshooting Media Player Output

Resolving no sound issues from the USB/SD card player.

Troubleshooting External Input Sound

Diagnosing and resolving no sound from external audio sources.
